型号/Model：DC24V-800W-C
规格参数/Specification：
1. 额定电压/Rated Voltage：DC 24V
2. 空载转速/No-load Speed：4000RPM±5%
3. 空载电流/No-load Current：≤3.5A
4. 额定转矩/Rated Torque：2N.m
5. 额定转速/Rated Speed：3100RPM±5%
6. 额定电流/Rated Current：45A
7. 额定功率/Rated Power：800W
Specification：
型号 Models | 额定电压 Rated Voltage | 额定电流 Rated Current | 额定功率 Rated Power | 额定转矩 Rated Torque | 绝缘等级 Insulation Grade | 转向 Rotation | 重量 Weight （Kg） |
DC12V1600W | 12V | 220A | 1600W | 6.0N.m | F | CW | 7.2 |
DC24V2200W | 24V | 130A | 2200W | 6.0N.m | F | CW | 7.2 |
DC24V800W | 24V | 45A | 800W | 2.0N.m | F | CW | 2.4 |
DC48V800W | 48V | 23A | 800W | 2.0N.m | F | CW | 2.6 |
DC60V800W | 60V | 12A | 800W | 2.0N.m | F | CW | 2.6 |
DC24V500W | 24V | 40A | 500W | 1.5N.m | F | CW | 2.1 |
DC48V500W | 48V | 20A | 500W | 1.5N.m | F | CW | 2.2 |
DC60V500W | 60V | 12A | 500W | 1.5N.m | F | CW | 2.2 |
DC48V400W | 48V | 8A | 500W | 1.2N.m | F | CW | 2.2 |
