型号/Model：XC07F10M01WS
规格参数/Specification：
1. 电机/Motor：DC 48V, 23A, 0.8KW, 2Nm, 3100RPM
2. 排量/Displacement：0.5cc/r
3. 油路块/Valve Block：84x84x32/45mm
4. 节流阀/Throttle Valve：G1/4-3L (∅1.4)
5. 油箱容积/Tank Capacity：1L
6. 安装方式/Mounting：卧式/Horizontal
7. 电磁阀/Solenoid：DC 48V 二位三通/2-position 3-way
8. 压力/System Pressure：16MPa
9. 出油口/Oil Port：G1/4
10. 工作制/Working System：S3
